Assignment 3: Domain Extensions and JSON Persistence

Update log

• 2/8/2026: Note error in handout test MarkdownExporterTest.java line 57: assertTrue(markdown.contains("- 2 cup flour")); should be assertTrue(markdown.contains("- 2 cups flour"));

Overview

In this assignment, you'll expand the CookYourBooks application in two major directions: domain modeling and persistence architecture. You'll create the structures needed to organize recipes into collections (published cookbooks, personal recipe boxes, web imports) and manage a user's library, then implement persistence using JSON serialization and export capabilities using Markdown.

This assignment emphasizes separating concerns between your core domain logic and external concerns like storage and file formats. By defining clear repository interfaces (what your application needs) and concrete implementations (how those needs are fulfilled), you create a system that's easier to test, maintain, and extend.

This is the first assignment where AI assistants are encouraged. The domain modeling and serialization work includes plenty of design decisions and boilerplate code—perfect for practicing effective AI collaboration.

Due: Thursday, February 12, 2026 at 11:59 PM Boston Time

Prerequisites: This assignment builds on the A2 sample implementation (provided). You should be familiar with Recipe, Quantity, Ingredient, and the conversion system from Assignments 1 and 2.

Starter Code: We provide all interface definitions and supporting types so you can focus on implementation and design decisions rather than transcription. See What's Provided for details.

How to Succeed on This Assignment

This assignment has more moving parts than previous ones. Here's a pacing strategy that works:

1. Read this handout when it's released. Skim the whole thing to understand the scope. You don't need to understand every detail yet—just get the big picture.

2. Look at the starter code on Friday. Open the files, read through CookbookImpl (the reference implementation), and start connecting the handout to actual code.

3. Post questions on the discussion board. If something in the handout or starter code doesn't make sense, ask. Early questions help everyone.

4. Work incrementally over several days. Don't try to do everything in one session. Let ideas settle. Come back with fresh eyes.

5. If you're stuck for more than 30 minutes on an error: STOP. Post on the discussion board, then go do something else for a few hours (or the rest of the day). Banging your head against an error rarely helps—stepping away often does, especially if you left a post on the discussion board asking for help.

6. Submit early and often. The submission limit is 15 per rolling 24 hours—that's plenty! Early in the week, go wild with submissions. Each one gives you free feedback from the autograder. Submissions early in the week don't count against your limit later, so use them to check your progress and catch issues early.

The discussion board is your best resource. As you learned in the requirements lab, asynchronous communication has real value. Post your error publicly (anonymously or not), and course staff can click your name to see your latest submission with your code. This lets us help point you in the right direction—and your question helps future students with the same issue.

Learning Outcomes

By completing this assignment, you will demonstrate proficiency in:

• Separating concerns by defining interfaces for persistence and implementing them independently (L16: Design for Testability)
• Designing repository interfaces that abstract persistence concerns from domain logic
• Implementing JSON serialization with Jackson, including polymorphic type handling
• Using AI coding assistants effectively for boilerplate generation and design exploration
• Evaluating AI-generated code for design quality and alignment with specifications
• Writing comprehensive tests that validate behavior and detect faults in complex systems

AI Policy for This Assignment

This is the first assignment where AI coding assistants are encouraged. You may (and should!) use tools like GitHub Copilot or Cursor throughout this assignment.

Why These Tools?

We specifically recommend IDE-integrated assistants (Copilot, Cursor) over other options:

• Not Claude Code or similar "agentic" tools: These tools are designed to work autonomously with minimal human oversight. Our course values keeping the human at the center of the development process—you should be reviewing, understanding, and directing every change. Agentic tools that make many changes without a well-designed review process automatically work against developing these skills. Yes, Claude Code has a VSCode extension, but it is our editorial opinion that it is poorly designed to support human review and iteration.

• Not ChatGPT, Claude.ai, or other web interfaces: Manually copying code between a browser and your IDE is a waste of your time. You lose the context of your codebase, can't easily iterate on suggestions, and spend cognitive effort on mechanics rather than thinking about design. IDE-integrated tools see your code directly and let you accept, reject, or modify suggestions in place.

The goal is AI as a collaborative partner, not AI as a replacement for thinking or a source of friction in your workflow.

However, effective AI usage requires skill. Simply copy-pasting the assignment into an AI and submitting its output will likely result in:

• A learning debt: you may get a reasonable submission, but you will not have learned the concepts and skills required to complete the assignment and will struggle to complete future assignments.
• Random features that appear to be implemented, and upon closer inspection have a comment along the lines // In production, you would actually implement serialization, for now we'll just use a placeholder
• A submission that passes all autograder tests, but might lose almost all of the manual grading points due to poor design or test suite quality.

Instead, use AI as a collaborative tool:

• Break problems into smaller pieces
• Provide context about your existing code
• Review and test AI suggestions before accepting them
• Iterate when the first attempt isn't right
• Understand what the code does before submitting it

The AI Workflow Guide section provides detailed guidance on effective AI usage for each part of this assignment.

You must document your AI usage in the Reflection section. This helps you develop metacognitive skills about when and how AI assists your learning.

Setup: Re-Enable AI Features

In Lab 1, you disabled AI features in VS Code to build foundational skills. Now it's time to turn them back on!

To re-enable AI features:

1. Open VS Code Settings:
   • Mac: Press ⌘+, (Command + comma)
   • Windows/Linux: Press Ctrl+,
2. In the search bar, type: chat.disableAIFeatures
3. Uncheck the box next to "Chat: Disable AI Features"

Or click this link: vscode://settings/chat.disableAIFeatures

You should now see the Copilot icon in your editor and have access to chat features. If you don't have GitHub Copilot set up yet, see the GitHub Copilot documentation for setup instructions.

AI Workflow Guide

This section provides structured guidance for using AI assistants effectively on each part of this assignment. The goal is not to minimize AI usage, but to maximize its effectiveness while ensuring you understand and can defend your code.

Task Categories

Different tasks benefit from AI assistance in different ways:

Task Type	AI Value	Strategy
Understanding handout code	High	Ask AI to explain unfamiliar patterns, annotations, design decisions
Boilerplate code (Jackson annotations, getters)	High	Let AI generate, review for correctness
Design decisions (data structures, relationships)	Moderate	Think first, then ask AI for alternatives or to expand your design into diagrams
Test generation	Moderate	AI for ideas, you verify they're meaningful
MarkdownExporter tests	High	Format is precisely specified; AI generates tests, you verify expected values
Debugging	High	Use scientific debugging, supported by AI

Managing Your AI Assistant

IDE-integrated assistants like Copilot and Cursor are powerful, but require some skill to use effectively. Here's what you need to know:

Copilot Chat Modes

Copilot offers different interaction modes. Choose the right one for your task:

Mode	What It Does	Best For
Ask	Answers questions, explains code. Read-only—won't change files.	Understanding starter code, learning patterns, debugging
Edit	Makes targeted changes to specific files you select.	Small, focused edits where you know exactly what to change
Agent	Autonomously explores codebase, reads files, runs commands.	Multi-file tasks, when AI needs to find relevant code

For this assignment: Start with Ask mode to understand the starter code and patterns. Use Edit mode for small, focused changes. Use Agent mode when the AI needs to explore your codebase to find relevant examples.

Project-Specific Context Limitations

AI assistants don't automatically understand all your project conventions. For example:

• The starter code uses NullAway with @NonNull as the default—most parameters don't need explicit annotations. However, an AI trained on general Java code may add @NonNull annotations everywhere because that's the common pattern in other codebases.
• Your project may have specific naming conventions, package structures, or patterns that the AI won't know unless you tell it.

If the AI keeps making the same mistake, add a note to your prompt: "This project uses NullAway with @NonNull as the default, so don't add @NonNull annotations unless the existing code does."

Task Scope: Start Small

AI Assistants Want to "Help" Too Much

If you give an AI assistant a large, vague task ("Implement all the collection classes"), it will often get stuck in a loop, generating and regenerating code without converging.

The AI is eager to finish the whole assignment for you. This is not helpful for learning.

The key principle: Only accept code you understand.

Why this matters:

1. Smaller changes are easier to review. You can actually verify the code is correct.
2. You stay in control. If something is wrong, you know exactly where to look.
3. You build understanding. Reviewing small pieces teaches you the patterns.
4. The AI produces better code. Focused prompts get focused, accurate responses.

As you practice specifying and reviewing AI-generated code, you'll develop intuition for what task sizes work well. Early on, err on the side of smaller tasks. You can always ask for more.

Suggested Prompts by Task

Your IDE (Copilot, Cursor) automatically provides context from your open files and codebase. Use this to your advantage—reference classes by name rather than describing them.

Domain Modeling (Cookbook, TableOfContents, UserLibrary)

Think first, then validate with AI:

I need to design a Cookbook class. See Recipe for the pattern I've been using for immutability.

Cookbook needs: title, optional author, optional ISBN, list of recipes.

I'm thinking of [your design approach]. What are the tradeoffs? Please draw a diagram of the class and its relationships to other classes in this codebase.

Why think first? Design decisions affect your entire codebase. AI can suggest patterns, but you need to understand why you're choosing one approach over another.

JSON Serialization Setup

Learn by experimenting, then use AI for debugging:

The starter code already includes all necessary Jackson annotations on the A2 classes. Your task is to understand how they work and apply similar patterns to your collection implementations.

Step 1: Experiment with serialization by hand

Before writing repository code, write a simple test to see how Jackson serializes your domain objects:

ObjectMapper mapper = new ObjectMapper();
mapper.registerModule(new Jdk8Module());

Recipe recipe = new Recipe(...);  // Create a test recipe
String json = mapper.writeValueAsString(recipe);
System.out.println(json);  // See the JSON structure

Recipe restored = mapper.readValue(json, Recipe.class);
assertEquals(recipe, restored);  // Verify round-trip

Why experiment first? Understanding the JSON structure helps you debug serialization issues and design your collection serialization. You'll see how @JsonTypeInfo adds the "type" field for polymorphic classes.

Step 2: Apply the pattern to your collection implementations

Your collection classes (CookbookImpl, etc.) need similar annotations. Use AI to help:

I'm implementing CookbookImpl which implements the Cookbook interface. I need to set up
Jackson annotations for polymorphic serialization, similar to how Quantity and Ingredient
are configured in the starter code.

Help me add the appropriate @JsonTypeInfo, @JsonSubTypes, and @JsonCreator annotations.

Debugging prompts:

• "The deserialization is failing with [error]. What's wrong?"
• "How do I handle the Optional fields in my collection classes?"
• "My collection deserializes as the wrong type. How do I fix this?"

Test Generation

AI for ideas, you for verification:

I'm testing JsonRecipeCollectionRepository. I need to verify that
different collection types (Cookbook, PersonalCollection, WebCollection)
all serialize and deserialize correctly.

Outline a comprehensive testing strategy for the JsonRecipeCollectionRepository.

Critical: AI-suggested tests may not be meaningful. For each suggestion, ask:

• Does this test a distinct behavior?
• Would this catch a real bug?
• Is the expected result correct?

Review Checklist

Before accepting AI-generated code, verify:

• Compiles: Does it compile without errors?
• Edge cases: What happens with empty strings, empty collections, special characters?
• Meets quality requirements: Does the code meet the quality requirements specified in the assignment?
• Tested: Have you written tests that pass on this code?
• Understood: Can you explain what this code does and why? Does it have meaningful comments?

Iteration Strategies

When AI output isn't quite right:

1. Be specific about the problem: "This code fails when the input is [X], I think because [Y] - trace through the code and identify any likely bugs that would cause this to happen"
2. Provide context: Explicitly refer to existing parts of your codebase that are relevant to the problem, or additional aspects of the specification that are relevant.
3. Ask for explanation: "Why did you use [approach]? What are the alternatives?"
4. Request modifications: "Modify this to also handle [case]"
5. Try a different approach: "That approach is getting complicated. Is there a simpler way?"

Development Checkpoints

Use these checkpoints to verify your understanding and progress:

Checkpoint 0: Understanding the Provided Code (Start Here)

Before writing any code, use AI to understand the substantial codebase you're inheriting:

Recommended AI Task: Ask AI to explain the provided code. You're inheriting interfaces, domain classes with Jackson annotations, and design patterns you may not have seen before.

Suggested prompts:

Explain the RecipeCollection interface hierarchy. What's the relationship between
RecipeCollection, Cookbook, PersonalCollection, and WebCollection?

I see @JsonTypeInfo and @JsonSubTypes annotations on the Quantity class. What do these
do and why are they needed?

Walk me through the Recipe class. What are the key fields and how does the constructor
handle null IDs?

What is the Builder pattern? Explain how CookbookImpl.Builder works and why we use it
instead of a constructor with many parameters.

Goal: Before implementing anything, you should be able to explain:

• The interface hierarchy for collections
• How Jackson polymorphic serialization annotations work
• What the Builder pattern provides
• How immutability is maintained in the domain classes

Checkpoint 1: After Studying CookbookImpl Reference

CookbookImpl is provided as a complete reference implementation. Before implementing PersonalCollectionImpl and WebCollectionImpl:

• Verify you understand how CookbookImpl implements the Cookbook interface
• Understand the Jackson annotations (@JsonCreator, @JsonProperty) on the constructor
• Understand the Builder pattern implementation and validation logic

Checkpoint 2: After Implementing PersonalCollectionImpl

• Run the starter tests to verify basic functionality
• Manually serialize a PersonalCollection and inspect the JSON:

  ObjectMapper mapper = new ObjectMapper();
  mapper.registerModule(new Jdk8Module());
  String json = mapper.writeValueAsString(myCollection);
  System.out.println(json);  // Verify the JSON structure

• If serialization fails, ask AI for debugging help with the specific error message

Checkpoint 3: Before Implementing JsonRecipeCollectionRepository

• Experiment with serialization in an isolated test
• Verify polymorphic round-trip for all collection types
• Ask AI: "How do I configure Jackson to preserve the concrete type when deserializing a RecipeCollection?"

Checkpoint 4: Before Writing Comprehensive Tests

• Review the mutation testing requirements in the grading rubric
• Ask AI: "What test cases would catch common bugs in a repository implementation?"

Checkpoint 5: MarkdownExporter Tests (AI-Recommended Task)

This is an ideal task for AI assistance. The format is precisely specified, making this an excellent use of AI for mechanical test generation.

Suggested prompt:

I need to write tests for MarkdownExporter.exportRecipe(). The required format is:

# {Recipe Title}

_Serves: {servings}_

## Ingredients

- {ingredient1.toString()}
- {ingredient2.toString()}

## Instructions

{instruction1.toString()}
{instruction2.toString()}

---

_Exported from CookYourBooks, learn more at https://www.cookyourbooks.app_

Generate JUnit 5 tests covering:
- Recipe with all fields (title, servings, ingredients, instructions)
- Recipe without servings (omit the Serves line)
- Empty ingredients list
- Empty instructions list
- Multiple ingredients and instructions
- Special characters in title/ingredient names

Your responsibility: Verify each generated test has correct expected values. AI may generate plausible-looking tests with wrong expectations.

Technical Specifications

Domain Concepts

Recipe Collections

Recipes come from many sources, and CookYourBooks needs to handle them all:

• Published cookbooks: Physical or digital books with ISBN, author, publisher, publication year. May have page numbers and a formal table of contents with chapters.
• Personal collections: A family recipe binder, a folder of index cards, grandmother's handwritten notes. Has a title and maybe some organization, but no formal publication metadata.
• Websites: Recipes scraped or imported from cooking websites. Has a URL, possibly a site name, maybe a date accessed.

Your challenge is to implement concrete classes that fulfill these interface contracts. The interfaces define an inheritance hierarchy (Cookbook, PersonalCollection, WebCollection extending RecipeCollection), and CookbookImpl is provided as a complete reference implementation. Your task is to:

• Study how CookbookImpl implements the pattern (immutability, Builder, Jackson annotations)
• Apply the same pattern to PersonalCollectionImpl and WebCollectionImpl
• Use AI assistants effectively to understand unfamiliar patterns and generate similar code

This is an excellent opportunity to practice AI-assisted pattern replication—a common real-world task where you study existing code and extend it consistently.

Important: Your implementations of PersonalCollectionImpl and WebCollectionImpl must include Jackson annotations (@JsonCreator, @JsonProperty) on a private constructor for deserialization to work. Study how CookbookImpl does this—the stub files provide the method signatures but you must add the constructor and annotations following the same pattern.

User Library

A user library is a user's personal collection of recipe collections. Users might own physical cookbooks they've digitized, maintain personal recipe collections, and save recipes from websites—all in one unified library.

Architecture Overview

This assignment separates your application into layers:

1. Model: Your core business logic—Recipe, Ingredient, Cookbook, etc. No dependencies on external systems like files or databases.

2. Repository Interfaces: Contracts that define what your application needs. For example, a RecipeRepository interface defines operations like save() and findById() without specifying how they're implemented.

3. Concrete Implementations: Classes that fulfill interface contracts. A JsonRecipeRepository implements RecipeRepository using JSON file storage.

This separation enables:

• Testability: Test domain logic with mock repositories
• Flexibility: Swap JSON storage for a database without changing domain code
• Clarity: Each component has a single responsibility

What's Provided

The starter code includes all interface definitions so you can focus on implementation:

Provided	Description
RecipeCollection.java	Base interface for all collections (with Jackson annotations)
Cookbook.java	Interface for published cookbooks
PersonalCollection.java	Interface for personal collections
WebCollection.java	Interface for web-sourced collections
SourceType.java	Enum with PUBLISHED_BOOK, PERSONAL, WEBSITE
UserLibrary.java	Interface for user's recipe library
RecipeRepository.java	Interface for recipe persistence
RecipeCollectionRepository.java	Interface for collection persistence
RepositoryException.java	Unchecked exception for persistence failures
Recipe.java (updated)	Now includes id field with auto-generation
JsonRecipeRepository.java	Stub with ObjectMapper configuration (you complete)
JsonRecipeCollectionRepository.java	Stub with ObjectMapper configuration (you complete)
MarkdownExporter.java	Stub class (you complete)
CookbookImpl.java	Complete reference implementation (study this!)
PersonalCollectionImpl.java	Stub implementation class (you complete)
WebCollectionImpl.java	Stub implementation class (you complete)
UserLibraryImpl.java	Partial implementation (you complete search methods)
RecipeCollectionTest.java	Starter test file (you expand)
UserLibraryTest.java	Starter test file (you expand)
JsonRecipeRepositoryTest.java	Comprehensive tests provided (minimal expansion needed)
JsonRecipeCollectionRepositoryTest.java	Starter test file (you expand)
MarkdownExporterTest.java	Starter test file (you expand)

What You Implement

Your Code	Description
PersonalCollectionImpl	Implement following CookbookImpl pattern
WebCollectionImpl	Implement following CookbookImpl pattern
UserLibraryImpl (4 methods)	Complete the search methods (partial implementation provided)
JsonRecipeRepository	Complete the provided stub
JsonRecipeCollectionRepository	Complete the provided stub
MarkdownExporter	Complete the provided stub
Test files	Expand starter tests (except JsonRecipeRepositoryTest which is provided)

Class Design

The diagram below shows the complete architecture. Blue dashed classes are provided interfaces; yellow classes are what you implement.

Legend:

• Gray classes: From A1/A2 (provided in starter code)
• Blue dashed classes: Interfaces (provided in starter code)
• Green classes: Reference implementations (provided, study these)
• Yellow classes: Classes you implement

Recipe ID Field

The RecipeRepository interface requires recipes to have unique identifiers for findById() and delete() operations. The starter code already includes an id field in Recipe:

// Recipe constructor now accepts an optional id parameter:
public Recipe(
    @Nullable String id,  // null = auto-generate UUID
    String title,
    @Nullable Quantity servings,
    List<Ingredient> ingredients,
    List<Instruction> instructions,
    List<ConversionRule> conversionRules)

// Recipe now has:
public @NonNull String getId()  // Returns the unique identifier

IDs are auto-generated as UUIDs if not explicitly set (when id parameter is null). This ensures globally unique identifiers with near-zero collision probability. When a caller provides an id, it is assumed that the caller guarantees uniqueness.

Note: Repository implementations assume IDs do not contain special characters that would be invalid in filenames. Auto-generated UUIDs satisfy this constraint.

Provided Interfaces

The following interfaces are provided in starter code. You must implement them but don't need to create the interface files. You must not modify the provided interfaces.

Collection Interfaces (Provided)

Interface	Extends	Key Methods
RecipeCollection	—	getId(), getTitle(), getSourceType(), getRecipes(), findRecipeById(), containsRecipe(), addRecipe(), removeRecipe()
Cookbook	RecipeCollection	getAuthor(), getIsbn(), getPublisher(), getPublicationYear()
PersonalCollection	RecipeCollection	getDescription(), getNotes()
WebCollection	RecipeCollection	getSourceUrl(), getDateAccessed(), getSiteName()

All collection implementations must be immutable—transformation methods like addRecipe() return new objects.

Behavioral Specifications:

• findRecipeById(String): Returns the recipe with the given ID, or Optional.empty() if not found.
• containsRecipe(String): Returns true if a recipe with the given ID exists in this collection.
• addRecipe(Recipe): Appends the recipe to the end of the list. Throws IllegalArgumentException if a recipe with the same ID already exists in the collection.
• removeRecipe(String): Returns a new collection with the recipe removed. Throws IllegalArgumentException if no recipe with the given ID exists in the collection.
• Recipe Order: Recipe order is preserved and significant for equality comparisons.
• Equality: Two collections are equal if they have the same ID, title, source type, type-specific metadata, and recipes (in the same order). The collection ID is part of equality.

Note on Optional Fields: All optional fields in collection interfaces return Optional<T> to clearly signal when a value is not specified. This includes both String fields (e.g., Cookbook.getAuthor() returns Optional<String>) and non-String fields (e.g., Cookbook.getPublicationYear() returns OptionalInt, WebCollection.getDateAccessed() returns Optional<LocalDate>). Using Optional consistently provides type safety and forces explicit handling of missing values.

Blank String Handling: Blank strings (empty or whitespace-only) for optional String fields are treated as absent and must return Optional.empty(). For example, if a Cookbook is constructed with author = "", then getAuthor() must return Optional.empty().

SourceType (Provided)

public enum SourceType {
    PUBLISHED_BOOK,  // Published cookbook with ISBN, author, publisher
    PERSONAL,        // Personal recipe collection (family recipes, etc.)
    WEBSITE          // Recipes imported from a website
}

Metadata by Collection Type

Interface	Required Fields	Optional Fields
Cookbook	title	author, ISBN, publisher, publication year
PersonalCollection	title	description, notes
WebCollection	title, source URL	date accessed, site name

Blank String Handling for WebCollection: The siteName field follows the same blank string normalization as other optional String fields—blank strings (empty or whitespace-only) are treated as absent and getSiteName() must return Optional.empty().

Optional Field Conventions:

• All optional fields return Optional<T>; use Optional.empty() to signal "not specified"
• This includes both String fields (author, ISBN, publisher, description, notes, site name) and non-String fields (publication year, date accessed)
• Using Optional consistently provides type safety and makes the API more explicit about missing values

Your Implementation: Collection Classes

You must provide concrete classes that implement each collection interface. How you structure your implementations is a design decision.

Required Implementation Names and Builders:

Each collection type must have a named implementation class with a builder for construction:

Interface	Implementation Class	Builder
Cookbook	CookbookImpl	CookbookImpl.builder()
PersonalCollection	PersonalCollectionImpl	PersonalCollectionImpl.builder()
WebCollection	WebCollectionImpl	WebCollectionImpl.builder()

Each builder must support:

• id(String) — optional, auto-generates UUID if not set
• title(String) — required
• recipes(List<Recipe>) — defaults to empty list if not set
• Type-specific fields (e.g., author(String) for CookbookImpl)
• build() — returns the constructed collection

Builder Validation:

• Calling build() without setting title throws IllegalStateException
• Calling title() with a blank string (empty or whitespace-only) throws IllegalArgumentException immediately (not at build() time)
• Calling recipes() with a list containing duplicate recipe IDs throws IllegalArgumentException
• For WebCollectionImpl: calling build() without setting sourceUrl throws IllegalStateException (since sourceUrl is required)
• All builder methods require non-null arguments where applicable (enforced by NullAway at compile time)

Example usage:

Cookbook cookbook = CookbookImpl.builder()
    .title("The Joy of Cooking")
    .author("Irma S. Rombauer")
    .publicationYear(1931)
    .build();

What We Test:

We test through the interfaces and RecipeCollectionRepository:

• save() followed by findById() returns an equal collection
• getSourceType() returns the correct type after round-trip
• getRecipes() returns all recipes after round-trip
• Type-specific methods (e.g., getAuthor() on Cookbook) return correct values after round-trip
• Polymorphism is preserved: saving a Cookbook and loading it returns a Cookbook, not just a RecipeCollection

Document your implementation approach and rationale in your reflection.

Your Implementation: UserLibraryImpl

A user's collection of recipe collections. The UserLibrary interface is provided and defines the core operations:

Method	Description
getCollections()	Returns all collections in the library (order unspecified)
addCollection(RecipeCollection)	Returns new library with collection added
removeCollection(String collectionId)	Returns new library with collection removed
findRecipesByTitle(String title)	Searches recipes across all collections (case-insensitive exact match)
findCollectionById(String id)	Finds a collection by ID
findCollectionByTitle(String title)	Finds a collection by title (case-insensitive exact match)
findAllCollectionsByTitle(String title)	Finds all collections with the given title
findRecipeById(String id)	Finds a recipe by ID across all collections

Behavioral Specifications:

• addCollection(RecipeCollection): Throws IllegalArgumentException if a collection with the same ID already exists. Collections with different IDs but the same title are both kept.
• removeCollection(String collectionId): Returns a new library with the collection removed. Throws IllegalArgumentException if no collection with the given ID exists.
• findRecipesByTitle(String title): Returns all recipes whose titles match the given title exactly (case-insensitive). The order of results is unspecified.
• findCollectionByTitle(String title): Returns any collection whose title matches the given title exactly (case-insensitive). If multiple collections have the same title, which one is returned is implementation-defined.
• findAllCollectionsByTitle(String title): Returns all collections whose titles match the given title exactly (case-insensitive). The order of results is unspecified.
• findRecipeById(String id): Searches all collections for a recipe with the given ID. Returns Optional.empty() if not found in any collection. If the same recipe ID exists in multiple collections (which should not normally occur), behavior is undefined.

Implementation Requirements:

• Your implementation must be named UserLibraryImpl
• Provide a constructor: public UserLibraryImpl(List<RecipeCollection> collections)
• An empty library can be created with new UserLibraryImpl(List.of())
• The library must be immutable—transformation methods return new instances
• The constructor does NOT validate for duplicate collection IDs—it accepts the list as provided. Duplicate ID validation only occurs when calling addCollection().

Persistence Note: UserLibrary is an in-memory convenience wrapper for working with multiple collections. There is no UserLibraryRepository—persistence happens at the collection level via RecipeCollectionRepository. To persist a library, save each collection individually. To restore a library, load all collections with findAll() and pass them to the UserLibraryImpl constructor.

Design Freedom:

You may add additional methods beyond the interface (e.g., getCollectionCount(), search by ingredient, filter by source type). These are not tested at the interface level but may be useful for your application.

Repository Interfaces (Provided)

Both repository interfaces are provided in starter code, along with RepositoryException.

Interface	Methods
RecipeRepository	save(Recipe), findById(String), findByTitle(String), findAllByTitle(String), findAll(), delete(String)
RecipeCollectionRepository	save(RecipeCollection), findById(String), findByTitle(String), findAllByTitle(String), findAll(), delete(String)

Key behaviors:

• save() replaces existing items with the same ID
• findByTitle() uses case-insensitive exact match; returns any one match if multiple exist (which match is returned is implementation-defined)
• findAllByTitle() returns all items with the given title (case-insensitive exact match); order is unspecified
• findAll() returns all items; order is unspecified
• delete() is a no-op if the item doesn't exist (idempotent for safe retries)
• All methods throw RepositoryException (unchecked) on I/O failures
• Title uniqueness is NOT enforced: Repositories may contain multiple items with the same title

Note on delete behavior: Repository delete() is idempotent (no-op if item doesn't exist) to support safe retries in persistence operations. In contrast, domain object methods like RecipeCollection.removeRecipe() and UserLibrary.removeCollection() throw IllegalArgumentException if the item doesn't exist—this enforces business rules and catches programming errors early.

Your Implementation: JSON Repositories

You must implement both repository interfaces using JSON file storage.

JsonRecipeRepository

Constructor:

• public JsonRecipeRepository(@NonNull Path storageDirectory)
  • Creates the directory if it doesn't exist
  • Throws RepositoryException if directory creation fails
  • Throws RepositoryException if the path exists but is not a directory
  • Throws RepositoryException if the directory contains corrupt or invalid JSON files when accessed (during findAll(), findById(), etc.)

Requirements:

• Must correctly serialize and deserialize all Quantity and Ingredient subtypes
• Must handle the polymorphic type hierarchy (see Polymorphic Serialization)
• Round-trip correctness: save(recipe) followed by findById(id) must return an equal recipe
• Must throw RepositoryException when encountering corrupt or invalid JSON files

Design Decisions (yours to make):

• JSON structure and field names
• How to encode type information for polymorphic classes

JsonRecipeCollectionRepository

Same requirements as JsonRecipeRepository, plus:

1. Polymorphic collections: Your JSON serialization must handle collection type polymorphism—saving a Cookbook and loading it back must return a Cookbook, not a generic RecipeCollection.

2. Nested recipes: Collections contain recipes. The simplest approach is to embed recipes directly in the collection JSON, which the provided Jackson annotations already support. This keeps each collection file self-contained.

Your Implementation: MarkdownExporter

Exports recipes and recipe collections to Markdown format.

Constructor:

• public MarkdownExporter() — no-arg constructor (stateless exporter)

Required Methods:

• @NonNull String exportRecipe(@NonNull Recipe recipe) - Returns the recipe as a Markdown string
• @NonNull String exportCollection(@NonNull RecipeCollection collection) - Returns the collection as a Markdown string
• void exportToFile(@NonNull Recipe recipe, @NonNull Path file) - Writes recipe to file; throws RepositoryException if the file cannot be written
• void exportToFile(@NonNull RecipeCollection collection, @NonNull Path file) - Writes collection to file; throws RepositoryException if the file cannot be written

Required Recipe Format:

The exportRecipe method must produce output in this exact format:

# {Recipe Title}

_Serves: {servings}_

## Ingredients

- {ingredient1.toString()}
- {ingredient2.toString()}

## Instructions

{instruction1.toString()}
{instruction2.toString()}

---

_Exported from CookYourBooks, learn more at https://www.cookyourbooks.app_

Format Details:

• If recipe has no servings, omit the _Serves: ..._ line entirely (no extra blank line—the title is followed by a single blank line, then ## Ingredients)
• Use Ingredient.toString() for ingredient formatting (from A1)
• Use Instruction.toString() for each instruction (includes step number and text, e.g., "1. Mix ingredients")
• The footer --- and _Exported from CookYourBooks, learn more at https://www.cookyourbooks.app_ are required
• Use Unix line endings (\n)
• If ingredients list is empty, include the ## Ingredients header with no list items
• If instructions list is empty, include the ## Instructions header with no list items
• Titles and ingredient names are included as-is without escaping markdown special characters

Required Collection Format:

The exportCollection method must produce output in this exact format:

## {Collection Title}

{metadata line - see below}

---

# {Recipe 1 Title}

...recipe format as specified above...

---

# {Recipe 2 Title}

...recipe format as specified above...

Metadata Line by Collection Type:

Collection Type	Metadata Line Format	Example
Cookbook	_By: {author}_ (if author present)	_By: Julia Child_
PersonalCollection	_{description}_ (if description present)	_Family recipes passed down for generations_
WebCollection	_Source: {url}_	_Source: https://example.com/recipes_

Format Details:

• Collection title uses H2 (##) to distinguish from recipe titles (H1)
• Metadata line is omitted entirely if the optional field is not present
• Recipes are separated by --- (horizontal rule)
• If a collection has no recipes, include only the header and metadata (no --- separators, no footer)
• Each recipe within the collection uses the recipe format without the individual recipe footer. Only the final recipe in the collection includes the CookYourBooks footer.
• Use Unix line endings (\n)

Example: Cookbook with one recipe:

## The Joy of Cooking

_By: Irma Rombauer_

---

# Chocolate Cake

_Serves: 8 whole_

## Ingredients

- 2 cup flour
- 1 cup sugar

## Instructions

1. Preheat oven to 350°F
2. Mix dry ingredients

---

_Exported from CookYourBooks, learn more at https://www.cookyourbooks.app_

Testing Note: The format is fully specified, making this an excellent task for AI-assisted test generation. See Checkpoint 5 in the AI Workflow Guide for suggested prompts.

Polymorphic Serialization

The Quantity and Ingredient class hierarchies require special handling during JSON serialization because Jackson needs to know which subclass to instantiate during deserialization.

Pre-Configured Jackson Annotations

We have already added all necessary Jackson annotations to the A2 starter code. This includes:

• @JsonTypeInfo and @JsonSubTypes on the abstract base classes (Quantity, Ingredient)
• @JsonCreator and @JsonProperty on all constructors (Recipe, Instruction, ExactQuantity, FractionalQuantity, RangeQuantity, MeasuredIngredient, VagueIngredient)

Records (IngredientRef, ConversionRule) work automatically with Jackson 2.12+ without additional annotations.

Test Serialization By Hand

Before implementing your repositories, we strongly encourage you to experiment with Jackson serialization directly. Write a simple test that:

1. Creates a Recipe with various Quantity and Ingredient types
2. Serializes it to JSON using ObjectMapper.writeValueAsString()
3. Prints the JSON to see the structure
4. Deserializes it back using ObjectMapper.readValue()
5. Verifies the round-trip produces an equal object

This hands-on experimentation will help you understand how the annotations work and what JSON structure your repository will produce. Understanding the serialization format is essential for debugging issues later.

How the Annotations Work

For polymorphic hierarchies, @JsonTypeInfo and @JsonSubTypes annotations on the base class tell Jackson how to handle subclasses. Combined with @JsonCreator on subclass constructors, this gives Jackson everything it needs:

// On the abstract base class:
@JsonTypeInfo(use = JsonTypeInfo.Id.NAME, property = "type")
@JsonSubTypes({
  @JsonSubTypes.Type(value = ExactQuantity.class, name = "exact"),
  @JsonSubTypes.Type(value = FractionalQuantity.class, name = "fractional"),
  @JsonSubTypes.Type(value = RangeQuantity.class, name = "range")
})
public abstract class Quantity {
  // ...
}

// On each subclass constructor:
public final class ExactQuantity extends Quantity {
  private final double amount;

  @JsonCreator
  public ExactQuantity(
      @JsonProperty("amount") double amount,
      @JsonProperty("unit") @NonNull Unit unit) {
    super(unit);
    // validation and initialization
  }
}

How it works:

• @JsonTypeInfo tells Jackson to include a "type" field in the JSON
• @JsonSubTypes maps type names ("exact", "fractional", etc.) to Java classes
• @JsonCreator on subclass constructors tells Jackson how to instantiate each type

Example JSON output:

{
  "type": "exact",
  "amount": 2.5,
  "unit": "CUP"
}

Note on architecture: Using Jackson annotations in domain classes introduces a dependency on Jackson. However, these are metadata annotations only—they don't change your domain logic or require Jackson at runtime unless you're serializing. For this course, we consider this an acceptable tradeoff for simplicity.

Alternative: Custom Serializers

If you want to keep domain classes completely annotation-free, you can write custom JsonSerializer and JsonDeserializer implementations. However, this requires significantly more code and is generally not worth the added complexity for this assignment.

equals() and hashCode() Requirements

Implement equals() and hashCode() for all your domain classes. The specific equality semantics depend on your design, but must satisfy:

• Collection equality: Two collections with the same ID, title, source type, type-specific metadata, and recipes (in the same order) should be equal
• Consistent with serialization: If two objects serialize to the same JSON, they should be equal
• Performance: It is trivial to satisfy these requirements by serializing and deserializing the objects. This is a huge performance penalty and should be avoided.

For example, if you have a Cookbook class with author and ISBN fields, two cookbooks with the same ID, title, author, ISBN, and recipes should be equal.

Design Requirements

• Immutability: All domain objects must be immutable. Transformation methods return new objects.
• Separation of concerns: Domain classes must not depend on Jackson, file I/O, or persistence implementations
• Interface abstraction: Code using repositories should depend on the interface, not JsonRecipeRepository
• Null safety: Use @NonNull and @Nullable annotations from JSpecify. Null parameters are enforced statically by NullAway—you do not need to throw exceptions for null arguments at runtime. Methods documented as requiring non-null parameters may assume the caller provides non-null values.
• Documentation: Javadoc for all public classes and methods
• Exception handling: Use RepositoryException (unchecked) for persistence failures

Testing Requirements

Testing follows the same model as Assignments 1 and 2:

• You must write tests for all components you implement. Your tests must be written to the interface provided, not to your implementation.
• Implementation points require tests: You only receive points for implementation if you have tests that detect plausible bugs
• Mutation testing: Your tests are run against intentionally buggy implementations
• Reference implementation: All your tests must pass on the instructor's reference implementation

Required Test Files:

Starter test files are provided in src/test/java/app/cookyourbooks/. You must expand these with your own tests:

Test File	What to Test
model/RecipeCollectionTest.java	Collection classes: construction, immutable transformations, equals/hashCode
model/UserLibraryTest.java	Library operations, recipe search across collections
adapters/JsonRecipeCollectionRepositoryTest.java	Collection persistence, polymorphic collection types, nested recipes
adapters/MarkdownExporterTest.java	Recipe format correctness; collection round-trip properties

Note: JsonRecipeRepositoryTest.java is provided with comprehensive tests and does not require expansion. It is not graded but serves as a reference for testing patterns.

Testing Guidance:

• Round-trip tests: save(obj) then findById(id) should return equal object
• Polymorphism tests: Verify that all your collection types (Cookbook, PersonalCollection, etc.) serialize and deserialize to the correct type
• Recipe polymorphism: Verify that ExactQuantity, FractionalQuantity, RangeQuantity, MeasuredIngredient, and VagueIngredient all serialize/deserialize correctly within collections
• Format tests: For exportRecipe, test exact string matches against expected Markdown output
• Round-trip tests for export: For exportCollection, we provide a starter test. Expand it to verify all recipe content and metadata appears in output (do not test exact format)
• Edge cases: Empty collections, null optional fields, special characters in names
• Error cases: Invalid input should throw appropriate exceptions

Avoid Fragile Tests

Several methods have unspecified ordering: findAll(), findAllByTitle(), UserLibrary.getCollections(), and UserLibrary.findRecipesByTitle() do not guarantee any particular order of results.

Do NOT write tests that depend on a specific order. For example:

// BAD: Assumes specific order - will fail on valid implementations
List<Recipe> results = repository.findAll();
assertEquals("Chocolate Cake", results.get(0).getTitle());
assertEquals("Vanilla Cake", results.get(1).getTitle());

// GOOD: Order-independent assertion
List<Recipe> results = repository.findAll();
assertEquals(2, results.size());
assertTrue(results.stream().anyMatch(r -> r.getTitle().equals("Chocolate Cake")));
assertTrue(results.stream().anyMatch(r -> r.getTitle().equals("Vanilla Cake")));

Similarly, findByTitle() returns "any one match" when multiple items share the same title. Tests should not assume which match is returned.

Tests that fail on correct implementations due to ordering assumptions will not receive credit.

AI and Testing:

AI can help generate test cases, but you must verify:

• The test actually tests something meaningful
• The expected values are correct
• Edge cases are covered
• The test would catch real bugs

Reflection

Complete the 6 reflection questions in REFLECTION.md. Each question is worth 4 points (24 points total). The questions cover:

1. AI-Assisted Pattern Replication - Describe how you used AI to understand the CookbookImpl reference implementation and apply its patterns to your other collection implementations. What prompts were effective? What did you have to (or choose to) figure out yourself?
2. Architecture and Testability - Specific examples of interface abstraction benefits
3. JSON Serialization - How polymorphic serialization works with Jackson annotations
4. AI Effectiveness - Which tasks AI helped most/least and why
5. AI for Understanding Code - How you used AI to understand the provided handout code
6. AI Iteration - A specific case where AI-generated code needed refinement

See REFLECTION.md for the complete question prompts and grading rubric.

Quality Requirements

Your submission should demonstrate:

• Correctness: Code compiles, follows specifications, passes tests
• Design Quality: Appropriate use of interfaces, immutability, information hiding
• Documentation: Clear Javadoc with design decisions explained
• Code Quality: Clean, readable code following course style conventions

Grading Rubric

[To be finalized after API review]

Automated Grading (76 points)

Implementation Correctness (40 points)

Your code is tested against a comprehensive instructor test suite:

Component	Points
RecipeCollection domain model (tested via repository)	10
UserLibrary	4
RecipeRepository interface compliance	2
RecipeCollectionRepository interface compliance	2
JsonRecipeRepository (round-trip correctness)	6
JsonRecipeCollectionRepository (round-trip correctness)	8
MarkdownExporter (exportRecipe format correctness)	4
MarkdownExporter (exportCollection format)	2
MarkdownExporter (exportToFile file I/O)	2

Test Suite Quality (36 points)

Your tests are evaluated using mutation testing as in the previous assignments:

Test File	Points	Notes
RecipeCollectionTest.java	10	Key focus: your collection implementations
UserLibraryTest.java	4	Test search methods you implement
JsonRecipeCollectionRepositoryTest.java	12	Main challenge: polymorphic collections
MarkdownExporterTest.java	10	AI-recommended task (see checkpoints)

Notes:

• You only receive implementation points if you also have tests that detect bugs in that component.
• MarkdownExporterTest.java is an excellent task for AI assistance—the format is precisely specified. See the AI Workflow Guide for suggested prompts.

Manual Grading (Subtractive, max -30 points)

Category	Max Deduction	Criteria
Architecture	-16	Domain depends on persistence implementations; missing interface abstractions; tight coupling
Immutability	-6	Mutable domain objects; exposed internal collections
Documentation	-4	Missing Javadoc; undocumented design decisions
Test Quality	-6	Trivial tests; tests don't verify meaningful behavior
Code Style	-10	Poor naming; overly complex logic; inconsistent style

Reflection (24 points)

See REFLECTION.md for the 6 reflection questions and detailed rubric. Each question is worth 4 points (6 questions × 4 points = 24 points total).

Repository Structure

Your final repository should include:

src/
├── main/java/app/cookyourbooks/
│   ├── model/
│   │   ├── RecipeCollection.java          (PROVIDED - interface)
│   │   ├── Cookbook.java                  (PROVIDED - interface)
│   │   ├── PersonalCollection.java        (PROVIDED - interface)
│   │   ├── WebCollection.java             (PROVIDED - interface)
│   │   ├── SourceType.java                (PROVIDED - enum)
│   │   ├── UserLibrary.java               (PROVIDED - interface)
│   │   ├── CookbookImpl.java              (PROVIDED - stub, YOU COMPLETE)
│   │   ├── PersonalCollectionImpl.java    (PROVIDED - stub, YOU COMPLETE)
│   │   ├── WebCollectionImpl.java         (PROVIDED - stub, YOU COMPLETE)
│   │   ├── UserLibraryImpl.java           (PROVIDED - stub, YOU COMPLETE)
│   │   └── ... (A1/A2 classes, provided)
│   ├── repository/
│   │   ├── RecipeRepository.java          (PROVIDED - interface)
│   │   ├── RecipeCollectionRepository.java (PROVIDED - interface)
│   │   └── RepositoryException.java       (PROVIDED)
│   └── adapters/
│       ├── JsonRecipeRepository.java      (PROVIDED - stub, YOU COMPLETE)
│       ├── JsonRecipeCollectionRepository.java (PROVIDED - stub, YOU COMPLETE)
│       └── MarkdownExporter.java          (PROVIDED - stub, YOU COMPLETE)
└── test/java/app/cookyourbooks/
    ├── model/
    │   ├── RecipeCollectionTest.java      (PROVIDED - starter, YOU EXPAND)
    │   └── UserLibraryTest.java           (PROVIDED - starter, YOU EXPAND)
    └── adapters/
        ├── JsonRecipeRepositoryTest.java  (PROVIDED - starter, YOU EXPAND)
        ├── JsonRecipeCollectionRepositoryTest.java (PROVIDED - starter, YOU EXPAND)
        └── MarkdownExporterTest.java      (PROVIDED - starter, YOU EXPAND)

File names in [brackets] may vary based on your design decisions.

Good luck! Remember: this assignment is designed to help you develop effective AI collaboration skills. Use AI assistants thoughtfully, test rigorously, and reflect on what works.

---

Appendix: JSON and Jackson Primer

This appendix provides background on JSON and the Jackson library for students who haven't worked with JSON serialization before.

What is JSON?

JSON (JavaScript Object Notation) is a lightweight text format for storing and exchanging data. Despite "JavaScript" in the name, JSON is language-independent and has become the de facto standard for data interchange on the web and in modern applications.

A JSON document is plain text that humans can read and machines can parse reasonably efficiently. It is so pervasive, that even if you haven't worked with it before, you've probably seen it before. Here's an example:

{
  "title": "Chocolate Chip Cookies",
  "servings": 24,
  "author": "Grandma",
  "tags": ["dessert", "baking", "cookies"],
  "published": true,
  "rating": null
}

JSON supports six data types:

Type	Example	Java Equivalent
String	"hello"	String
Number	42, 3.14, -7	int, double, BigDecimal
Boolean	true, false	boolean
Null	null	null
Array	[1, 2, 3], ["a", "b"]	List<T>, arrays
Object	{"key": "value"}	Java objects, Map<String, T>

Key syntax rules:

• Strings must use double quotes ("hello", not 'hello')
• Object keys must be strings ({"name": "value"}, not {name: "value"})
• No trailing commas ([1, 2, 3], not [1, 2, 3,])
• No comments (unlike Java, JSON has no comment syntax)

Why JSON Became Popular

JSON emerged in the early 2000s as a simpler alternative to XML (another popular data format at the time). Its rise to dominance came from several factors:

1. Human-readable: Unlike binary formats, you can open a JSON file in any text editor and understand its structure immediately.

2. Lightweight: JSON has minimal syntax overhead compared to XML. Compare:

   <recipe><title>Cookies</title><servings>24</servings></recipe>

   { "title": "Cookies", "servings": 24 }

3. Native to JavaScript: Web browsers can parse JSON directly with JSON.parse(), making it ideal for web APIs.

4. Schema flexibility: JSON doesn't require a predefined schema, making it easy to evolve data formats over time. This is a stark contrast to XML, which requires a predefined schema.

Today, JSON is used for:

• Data exchange between services (e.g. APIs)
• Configuration files (e.g. VS Code settings)
• Document databases (e.g. MongoDB stores JSON-like documents)

Jackson: Java's JSON Library

Jackson is the most widely-used JSON library for Java. It handles serialization (Java objects → JSON) and deserialization (JSON → Java objects). Jackson is already included in your project dependencies.

Simpler Examples Online

If you search for Jackson tutorials, you'll find simpler-looking examples using mutable classes with no-arg constructors and setters. These approaches won't work for this assignment because your domain classes must be immutable (final fields, no setters). The patterns below are what you need.

Jackson with Immutable Classes

Your domain classes are immutable—they have final fields and no setters. The default approach used by Jackson to create new objefcts from JSON is to use a no-arg constructor, and then to set each field one-by-one. However, this is not possible when your classes are immutable - the fields must be set in the constructor. Hence, you need to use the @JsonCreator annotation to tell Jackson how to construct instances:

import com.fasterxml.jackson.annotation.JsonCreator;
import com.fasterxml.jackson.annotation.JsonProperty;

public final class Person {
    private final String name;
    private final int age;

    @JsonCreator // This tells Jackson to use this constructor to create new instances from JSON
    public Person(
            @JsonProperty("name") String name, // This tells Jackson to map the JSON field "name" to the parameter name
            @JsonProperty("age") int age) { // This tells Jackson to map the JSON field "age" to the parameter age
        if (name.isBlank()) {
            throw new IllegalArgumentException("name must not be blank");
        }
        this.name = name;
        this.age = age;
    }

    public String getName() { return name; }
    public int getAge() { return age; }
}

How it works:

• @JsonCreator tells Jackson to use this constructor for deserialization
• @JsonProperty("name") maps the JSON field "name" to this constructor parameter
• Jackson uses your getters (getName()) to determine what fields to serialize
• Your validation logic in the constructor runs during deserialization

Serializing and deserializing:

The ObjectMapper class is used to serialize and deserialize Java objects to and from JSON.

When deserializing, you must specify the class of the object to deserialize to so that the return object is of the correct type. This type is not used to instantiate the object - that is done by the @JsonCreator annotation, so the code below will work even if the json string is a subclass of Person.

import com.fasterxml.jackson.databind.ObjectMapper;

ObjectMapper mapper = new ObjectMapper();

// Serialize: Java object → JSON string
Person person = new Person("Alice", 30);
String json = mapper.writeValueAsString(person);
// Result: {"name":"Alice","age":30}

// Deserialize: JSON string → Java object
Person restored = mapper.readValue(json, Person.class);

Working with collections:

// Serializing a list works directly
List<Person> people = List.of(new Person("Alice", 30), new Person("Bob", 25));
String json = mapper.writeValueAsString(people);
// Result: [{"name":"Alice","age":30},{"name":"Bob","age":25}]

// Deserializing a list requires TypeReference (due to Java type erasure)
List<Person> restored = mapper.readValue(json, new TypeReference<List<Person>>() {});

Handling Optional Fields

For backwards compatibility reasons, Java's Optional<T> needs special handling. Register the Jdk8Module with the ObjectMapper:

ObjectMapper mapper = new ObjectMapper();
mapper.registerModule(new Jdk8Module());

The starter code provides stub files for JsonRecipeRepository and JsonRecipeCollectionRepository with the ObjectMapper configuration already set up.

Now Optional fields work correctly:

public class Recipe {
    private final String title;
    private final Optional<String> author;

    @JsonCreator
    public Recipe(
            @JsonProperty("title") String title,
            @JsonProperty("author") Optional<String> author) {
        this.title = title;
        this.author = author != null ? author : Optional.empty();
    }

    // getters...
}

// Serialization
Recipe r1 = new Recipe("Cookies", Optional.of("Grandma"));
// {"title":"Cookies","author":"Grandma"}

Recipe r2 = new Recipe("Cookies", Optional.empty());
// {"title":"Cookies","author":null}  or  {"title":"Cookies"} depending on config

Handling Polymorphism (Inheritance)

This is the trickiest part. When you have a class hierarchy like Quantity with subclasses ExactQuantity, FractionalQuantity, and RangeQuantity, Jackson needs to know which subclass to instantiate during deserialization.

The problem:

// How to know which concrete Quantity subclass to instantiate?
{"amount": 2.5, "unit": "CUP"}

The solution: Add type annotations to the base class and use @JsonCreator on subclasses.

import com.fasterxml.jackson.annotation.JsonTypeInfo;
import com.fasterxml.jackson.annotation.JsonSubTypes;

@JsonTypeInfo(use = JsonTypeInfo.Id.NAME, property = "type") // This tells Jackson to add a "type" field to the JSON
@JsonSubTypes({
    @JsonSubTypes.Type(value = ExactQuantity.class, name = "exact"), // This tells Jackson to map JSON objects with a "type" field of "exact" to the ExactQuantity class
    @JsonSubTypes.Type(value = FractionalQuantity.class, name = "fractional"), // This tells Jackson to map JSON objects with a "type" field of "fractional" to the FractionalQuantity class
    @JsonSubTypes.Type(value = RangeQuantity.class, name = "range") // This tells Jackson to map JSON objects with a "type" field of "range" to the RangeQuantity class
})
public abstract class Quantity {
    // ...
}

How it works:

• @JsonTypeInfo(property = "type") tells Jackson to add a "type" field to the JSON
• @JsonSubTypes maps each type name to its corresponding Java class
• When deserializing, Jackson reads the "type" field first to determine which class to instantiate

This produces JSON like:

{"type": "exact", "amount": 2.5, "unit": "CUP"}
{"type": "fractional", "numerator": 1, "denominator": 2, "unit": "CUP"}
{"type": "range", "min": 2, "max": 3, "unit": "CUP"}

You'll need similar annotations on Ingredient (for MeasuredIngredient and VagueIngredient) and on RecipeCollection (for your collection implementations).

Common Errors and Solutions

Error	Cause	Solution
InvalidDefinitionException: Cannot construct instance	No suitable constructor	Add @JsonCreator to constructor
UnrecognizedPropertyException: Unrecognized field "xyz"	JSON has field your class doesn't	Add the field, or configure mapper to ignore unknown
InvalidTypeIdException: Missing type id	Polymorphic type without type field	Ensure @JsonTypeInfo is configured
JsonMappingException: No serializer found	Private fields without getters	Add getters, or configure field visibility

Ignoring unknown properties (useful during development):

mapper.configure(DeserializationFeature.FAIL_ON_UNKNOWN_PROPERTIES, false);

Testing JSON Round-Trips

A round-trip test verifies that serialization and deserialization preserve all data:

@Test
void recipeRoundTrip() throws Exception {
    ObjectMapper mapper = createObjectMapper();

    Recipe original = new Recipe(
        "test-id",
        "Chocolate Cake",
        new ExactQuantity(8, Unit.SERVING),
        List.of(new MeasuredIngredient("flour", new ExactQuantity(2, Unit.CUP), null, null)),
        List.of(new Instruction(1, "Mix ingredients", List.of())),
        List.of()
    );

    // Serialize to JSON
    String json = mapper.writeValueAsString(original);

    // Deserialize back
    Recipe restored = mapper.readValue(json, Recipe.class);

    // Verify equality
    assertEquals(original, restored);
}

Further Reading

• Jackson Project Home — Official documentation
• Baeldung Jackson Tutorial — Comprehensive tutorial series
• JSON Specification — The official JSON format specification

Ask Your AI Assistant

Jackson configuration can be tricky. This is a great place to use your AI assistant:

• "How do I configure Jackson to serialize LocalDate as a string?"
• "My deserialization is failing with [error]. What's wrong?"
• "How do I handle a field that might be missing in the JSON?"

Just remember to understand what the generated code does before using it.
