Lab 5: Requirements Engineering

In this lab, you'll experience firsthand why requirements analysis matters. You and a partner will interpret an intentionally ambiguous project brief, then discover how dramatically your interpretation differs from another pair's—even though you read the exact same words. This "parallel universe" exercise demonstrates the critical importance of building shared understanding before writing code.

Lo-fi pixel art showing a central scene of a developer at a desk, puzzling over a short requirements document titled 'OFFICE HOURS SYSTEM'. The document is small and sparse—just a few bullet points visible. Around the developer's head, multiple translucent thought bubbles float outward like branching possibilities: one shows a video call interface, another shows a chat window, another shows a physical queue of students, another shows a ticket system with numbers. Each bubble is equally vivid, equally plausible. On the desk, a highlighter rests on phrases circled with question marks. A sticky note reads 'What does this MEAN?' In the background, a whiteboard shows the three risk dimensions: 'Understanding? Scope? Volatility?' with arrows pointing to a large question mark. Title: 'Lab 5: Requirements Engineering'. Warm evening lighting, cozy study room atmosphere.

Grading: What You Need to Submit

Due: At the end of your scheduled lab section. This is automatically enforced with a 10-minute grace period, but push your work regularly—don't wait until the end!

Option 1: Complete entire lab

  • Complete Parts 1-5 of the lab
  • Complete the reflection in REFLECTION.md
  • Push your completed work to GitHub
  • You may leave the lab after confirming with a TA that you're done

Option 2: Complete what you are able and ask for help If you're unable to complete everything:

  • Submit a REFLECTION.md documenting what you completed, where you got stuck, and what you tried
  • A TA will review your submission and award credit for your good-faith effort
Attendance Matters

If lab leaders observe that you are not working on the lab during the section, or you leave early AND do not successfully complete the lab, you will receive no marks. However: if you finish the required parts of the lab and want to work on something else, just show the lab leader that you're done, and you'll be all set!

Struggling? That's okay! We are here to support you. If you're putting in effort and engaging with the material, we will give you credit. Ask questions, work with your neighbors, and flag down a lab leader if you're stuck.

Getting Started​

Your TA will provide a brief introduction and organize pairs. Important: During Parts 1 and 2, do not communicate with other pairs—this is essential for the exercise.

Soft Skill Focus: Building Shared Understanding

During pair work, practice these skills:

  • Explain your interpretation and the reasoning behind it
  • Listen to understand (not to argue)
  • Identify where your interpretations differ
  • Create a merged understanding that incorporates both perspectives

Step 1: Introduce yourself to your partner and record their name in REFLECTION.md.

Learning Objectives​

By the end of this lab, you will be able to:

  • Experience how the same requirements text can lead to dramatically different interpretations
  • Identify ambiguous terms and hidden assumptions in requirements documents
  • Apply the three risk dimensions (understanding, scope, volatility) to analyze requirements divergence
  • Practice building shared understanding through structured negotiation
  • Develop questions that would clarify ambiguous requirements

Before You Begin​

Prerequisites: Complete Lecture 9 (Interpreting Requirements). You should be familiar with:

  • The three dimensions of requirements risk (understanding, scope, volatility)
  • Stakeholder analysis and conflicting interests
  • Requirements elicitation techniques

Clone the Lab Repository: Clone your lab5 repository from Pawtograder.

The repository includes:

  • REFLECTION.md — where you'll record your interpretations, analysis, and reflections
  • This lab has no coding exercises—it's entirely about requirements analysis

The Scenario: Office Hours System​

You've been hired to build a system for the CS department. Here's the brief you received:

Project Brief

OFFICE HOURS SYSTEM

The CS department needs a system to help students get help from TAs.

Key points:

  • Students can request help with course material
  • TAs provide assistance during their scheduled hours
  • Some office hours are in-person, some are virtual
  • The system should support both live help and leaving questions for later
  • Students should know when they can expect a response
  • TAs need to manage their workload fairly

Build something that works for a course with 300 students and 10 TAs across three campuses in different time zones.

That's it. That's all you get.

Your job in this lab is to turn this vague brief into a concrete specification—and then discover what happens when different people interpret the same brief differently.

Part 1: Individual Interpretation (15 minutes)​

Work alone for this part. Do not discuss with your partner yet.

Read the project brief carefully. Then, working independently, complete the following exercises in your REFLECTION.md.

Exercise 1.1: Your Requirements​

List 5-7 specific requirements you believe the system needs. For each requirement:

  • State it clearly enough that another engineer could implement it
  • Note any assumptions you're making
  • Identify which stakeholder (student, TA, instructor, department) it primarily serves

Format:

Requirement: [A specific, testable requirement] Assumption: [What you assumed about the brief to arrive at this requirement] Stakeholder: [Who benefits and why]

Exercise 1.2: Ambiguity Identification​

List 3 or more terms or phrases from the brief that you found unclear or ambiguous. For each:

  • Quote the exact phrase
  • Explain why it's ambiguous
  • State what you assumed it means for your requirements above

Format:

Phrase: [Quote the exact words from the brief] Why ambiguous: [What different interpretations are possible?] My assumption: [Which interpretation you chose for your requirements]

Write your answers in the "Part 1: Individual Interpretation" section of REFLECTION.md before proceeding.

Part 2: Pair Negotiation (20 minutes)​

Now work with your partner. Still no communication with other pairs!

Exercise 2.1: Share Interpretations (10 minutes)​

Take turns sharing your individual interpretations from Part 1:

  • Read your requirements aloud to your partner
  • Discuss: Where do you agree? Where do you disagree?
  • Identify: What assumptions did each of you make?

Pay attention to moments where you made different assumptions about the same phrase. These are the most interesting findings.

Exercise 2.2: Joint Specification (10 minutes)​

Together, create a joint specification of exactly 8 requirements:

  • Each requirement must be specific enough that a developer could test whether it's been implemented correctly
  • Both partners must agree on the exact wording
  • Document any assumptions you're both making

Write your joint specification in the "Part 2: Pair Specification" section of REFLECTION.md.

The goal is consensus—you should both be able to defend every requirement as the "right" interpretation of the brief.

Sync Point

Wait here until your TA signals to proceed to Part 3.

Part 3: The Reveal (20 minutes)​

Now pairs combine into quads. This is where it gets interesting.

Exercise 3.1: Specification Comparison (10 minutes)​

Do NOT debate yet—just observe.

  1. Pair AB reads their 8 requirements aloud, one at a time
  2. Pair CD reads their 8 requirements aloud, one at a time
  3. As you listen, note every difference you hear—big or small

You'll likely discover that despite reading the exact same brief, your specifications describe different systems.

Exercise 3.2: Divergence Catalog (10 minutes)​

As a quad, create a table documenting every significant difference between the two specifications:

TopicPair AB's InterpretationPair CD's InterpretationImpact if Built Wrong
............

Aim for at least 4 divergences. You'll probably find more.

Record your divergence table in the "Part 3-4: The Reveal" section of REFLECTION.md.

Part 4: Root Cause Analysis (15 minutes)​

Exercise 4.1: Apply the Risk Framework (10 minutes)​

For your top 3 divergences, classify each by the risk dimension from Lecture 9:

DivergenceRisk TypeWhy This Classification?
[Your divergence 1]Understanding / Scope / Volatility[Your explanation]
[Your divergence 2]......
[Your divergence 3]......

For each, explain:

  • Why does this divergence fall into this risk category?
  • What would happen if you built one interpretation and the client wanted the other?

Exercise 4.2: What Would Have Helped? (5 minutes)​

For each of your top 3 divergences, identify which elicitation technique from Lecture 9 could have prevented it:

DivergenceElicitation TechniqueSpecific Action
[Your divergence 1]Interview / Observation / Prototype / etc.[What specifically would you do?]
[Your divergence 2]......
[Your divergence 3]......

Record your analysis in REFLECTION.md.

Sync Point

Wait here for a brief class discussion before proceeding to Part 5.

Part 5: Reflection and Insights (10 minutes)​

Exercise 5.1: User Perspective​

You're not just engineers—you're also potential users of an office hours system. As a quad, discuss:

  • Which interpretation from either pair would you actually want as a student?
  • Did the "engineer" interpretation match what the "user" would want?
  • What requirements did neither pair think of that you'd want as a user?

Exercise 5.2: Questions for the Client​

If you could ask the CS department 3 questions before building this system, what would they be?

  • Focus on questions that would resolve your biggest divergences
  • Frame questions to get useful answers (avoid yes/no questions)

Record your insights and questions in REFLECTION.md.

Reflection​

Your REFLECTION.md should include all of the following sections. Make sure you've completed each one before submitting:

Partner Information​

  • Your Pair Partner: [Name]
  • Your Quad Partners: [Names from the other pair]

Part 1: Individual Interpretation​

  • Your 5-7 initial requirements (with assumptions and stakeholders)
  • Your 3+ identified ambiguities (with your assumptions)

Part 2: Pair Specification​

  • Your joint 8 requirements
  • Assumptions you both made

Part 3-4: The Reveal​

  • Divergence table (at least 4 rows)
  • Risk classification table (top 3 divergences)
  • "What would have helped" table

Part 5: Reflection and Insights​

  • User perspective discussion (engineer vs. user interpretations)
  • 3 questions for the client

Meta Reflection​

Answer these questions thoughtfully:

  1. Most Surprising Divergence: What difference between the pairs surprised you most? Why didn't you anticipate it?

  2. Engineer vs. User: Did your "engineer" interpretation match what you'd actually want as a user of this system? What does that tell you about requirements gathering?

  3. Future Behavior: What will you do differently when reading requirements for your next assignment or project?

Submission Checklist​

Due: By the end of your lab section (with a 10-minute grace period).

Before your final submission, ensure:

  • Part 1: You completed your individual interpretation (5-7 requirements, 3+ ambiguities)
  • Part 2: You and your partner created a joint specification of exactly 8 requirements
  • Part 3: Your quad cataloged at least 4 divergences between the pair specifications
  • Part 4: You classified your top 3 divergences by risk type and identified elicitation techniques
  • Part 5: Your quad discussed user perspective and identified 3 questions for the client
  • REFLECTION.md is complete with all sections filled in
  • All changes are committed and pushed to GitHub
